Weight | 10 kg |
---|---|
Dimensions | 80 × 50 × 40 cm |
Extra: RTK Ricevitore | NO, SI |
Extra: Backpack | NO, SI |
Extra: Car Mount | NO, SI |
Extra: Spherical Camera | NO, SI |
Laser Scanning FOV | 270° x 360° |
Camera FOV | 200° (h) x 100° (v) |
Relative Accuracy | 2 cm |
Absolute Acuracy | 5 cm |
Storage | 32GB (standard) |
Power Supply | replaceable battery |
External Power Supply | 20-30V |
Battery Capacity | 3350mAh*4 |
Battery Duration | 2.5h |
Power Consumption | 25W |
Protection Class | IP54 |
Operating Temperature | -10°C / +45°C |
Operating Humidity | <85%RH |
Weight | 1588g (w/o battery) |
Size | 372mm x 163mm x 106mm |
Sensor Parameters: Laser Class | Class 1 |
Sensor Parameters: Number of laser channels | 16 |
Sensor Parameters: Maximum ranging | 120m |
Sensor Parameters: Dot frequency | 320kpts/s |
Sensor Parameters: Echo strenght | 8bits |
Sensor Parameters: Number of cameras | 3 |
Sensor Parameters: Camera resolution | 5Mpx |
Sensor Parameters: NFC | Support |
